BMW M2/M3/M4 AST 5300 Series Coilovers - M3/M4 (S58-G80 G82)

Revolutionary Inverted Shock Design

Delivery Cost?

RRP: £6,720.00 (inc. VAT)

Our Price: £6600.00 (inc. VAT)

Fully Fitted: £7,010.40 (inc. VAT)

Order quantity

Tweet

AST 5300 Series Coilovers - AST SUSPENSION

• 3-Way adjustable (12 clicks of independent rebound , 14 clicks of independent low speed compression, 12 clicks of independent high speed compression)
• Remote reservoirs for improved heat and fluid displacement
• Inverted strut designs for improved acceleration and cornering g-forces
• Improved piston diameter for improved fluid displacement
• Gas-pressurised for improved performance
• Fully ride-height adjustable (lowering from -25 to -60mm)
• Includes AST motorsport top mounts for camber control
• Reliable and low maintenance
• Suppled as true coilover rear shock setup

AST 5300 Series are 3-Way adjustable coilovers that are supplied with motorsport uniball top mounts, making them perfect for fast road, track day and racing usage.

The AST inverted damper system is a race-inspired design that gives the damper far more strength and resistance to high g-forces generated by fast driving. This design helps to retain the suspension geometry of the car during the cornering, braking and acceleration phases, ensuring consistent cornering performance.



The ride-height adjustment platform allows you to adjust the ride height of your car whilst retaining the maximum stroke of the damper.



AST's Monotube technology improves the damper's performance and efficiency by separating the damper oil and nitrogen gas inside the damper with a floating piston. This floating piston design, combined with the use of high-pressure nitrogen, helps to eliminate cavitation around the piston.



The larger piston and lack of cavitation increases the damper performance and the sensitivity of the dampers felt by the driver. All of this combines to produce more grip, increased control and improved driver feedback.



The three-way independent adjustability of the AST 5300 Series gives you complete control over the handling and chassis characteristics of your BMW M3. The control comes from the independently adjustable damping. You can set the low speed compression to a stiff setting for improved body control, especially during braking and cornering; then you can set the high speed compression far softer in order to smooth out any undulations on the road or race track. A good rebound setting will be able to compliment the stiff low-speed compression and the more supple high-speed compression. For this reason 3-Way adjustable coilovers are the ultimate choice for fast road, track day and race usage.



• Rebound, Low speed, and high speed compression are fully adjustable with remote reservoirs
• Remote reservoirs allow additional suspension travel, heat dissipation and oil/nitrogen capacity
• 44.5mm piston diameter offers exceptional strength, preventing unwanted geometry change during cornering and braking
• Aluminium shock bodies
• Threaded height-adjustable bodies
• Low friction internal seals
• Spherical lower "eye" shock mounts
• Reservoir with hose or piggyback system
• Spherical upper shock mount assemblies
• Synthetic hydraulic fluid
• Optional DLC coated 44.5mm inverted shafts
• Optional DDP (double digressive) piston
• Fully serviceable and rebuildable
• Custom valving available



AST 5300 Series Coilovers

The Pumaspeed Workshop team are ready to fit the BMW M2/M3/M4 AST 5300 Series Coilovers in our Head Office located here.

We estimate the labour time to be approximately 4.00 hour(s) costing £410.40 inc VAT.

Therefore making parts and labour a total cost £7,010.40 (inc. VAT).

Please don�t hesitate to contact us on the phone number above or click here to email.

Note: The fitting cost quoted is an estimate based on our Ford tuning experience. Please be aware that on rare occasions problems can occur that are out of our control; such as seized or snapped bolts due to age or wear. We work swiftly but in the event of an issue we may have to levy the fitting charge based on the time taken to rectify any unforeseen circumstances.

Pumaspeed Performance Distribution

Pumaspeed have a specialist distribution team that can dispatch the BMW M2/M3/M4 AST 5300 Series Coilovers to any destination worldwide.

Please select the delivery country from the drop down list below to see the express delivery charge and set your shopping cart to the correct VAT rate.

UK: Mainland UK: Highlands and Islands UK: Isle of Man UK: Isle of Wight Channel Islands Northern Ireland Afghanistan Albania Algeria American Samoa Andorra Angola Anguilla Antarctica Antigua and Barbuda Argentina Armenia Aruba Australia Austria Azerbaijan Bahamas Bahrain Bangladesh Barbados Belarus Belgium Belize Benin Bermuda Bhutan Bolivia Bosnia and Herzegowina Botswana Bouvet Island Brazil British Indian Ocean Territory Brunei Darussalam Bulgaria Burkina Faso Burundi Cambodia Cameroon Canada Cape Verde Cayman Islands Central African Republic Chad Chile China Christmas Island Cocos (Keeling) Islands Colombia Comoros Congo Cook Islands Costa Rica Cote D'Ivoire Croatia Cuba Cyprus, North Cyprus, South Czech Republic Denmark Djibouti Dominica Dominican Republic East Timor Ecuador Egypt Eire El Salvador Equatorial Guinea Eritrea Estonia Ethiopia Falkland Islands (Malvinas) Faroe Islands Fiji Finland France French Guiana French Polynesia French Southern Territories Gabon Gambia Georgia Germany Ghana Gibraltar Greece Greenland Grenada Guadeloupe Guam Guatemala Guinea Guinea-bissau Guyana Haiti Heard and Mc Donald Islands Honduras Hong Kong Hungary Iceland India Indonesia Iran (Islamic Republic of) Iraq Israel Italy Jamaica Japan Jordan Kazakhstan Kenya Kiribati Korea, Democratic People's Republic of Korea, Republic of Kuwait Kyrgyzstan Lao People's Democratic Republic Latvia Lebanon Lesotho Liberia Libyan Arab Jamahiriya Liechtenstein Lithuania Luxembourg Macau Macedonia Madagascar Malawi Malaysia Maldives Mali Malta Marshall Islands Martinique Mauritania Mauritius Mayotte Mexico Micronesia, Federated States of Moldova, Republic of Monaco Mongolia Montserrat Morocco Mozambique Myanmar Namibia Nauru Nepal Netherlands Netherlands Antilles New Caledonia New Zealand Nicaragua Niger Nigeria Niue Norfolk Island Northern Mariana Islands Norway Oman Pakistan Palau Panama Papua New Guinea Paraguay Peru Philippines Pitcairn Poland Portugal Puerto Rico Qatar Reunion Romania Russian Federation Rwanda Saint Kitts and Nevis Saint Lucia Saint Vincent and the Grenadines Samoa San Marino Sao Tome and Principe Saudi Arabia Senegal Seychelles Sierra Leone Singapore Slovakia (Slovak Republic) Slovenia Solomon Islands Somalia South Africa South Georgia and South Sandwich Spain Spain: Canaries Sri Lanka St. Helena Sudan Suriname Svalbard and Jan Mayen Islands Swaziland Sweden Switzerland Syrian Arab Republic Taiwan Tajikistan Tanzania, United Republic of Thailand Togo Tokelau Tonga Trinidad and Tobago Tunisia Turkey Turkmenistan Turks and Caicos Islands Tuvalu Uganda Ukraine United Arab Emirates United States United States Minor Outlying Islands Uruguay Uzbekistan Vanuatu Vatican City State (Holy See) Venezuela Viet Nam Virgin Islands (British) Virgin Islands (U.S.) Wallis and Futuna Islands Western Sahara Zaire Zambia Zimbabwe

Are you a trade customer?

Pumaspeed have a specialist trade distribution team that service many of the Motor trade specialists throughout the UK, the EU and the Rest of the World.

From a simple email tune file to a huge shipment of Milltek Sport Exhaust Systems. We have an expanding portfolio of new brands and products combined with the experience and ability to provide what you need.

To register your interest as a company click here.

No Reviews Yet
Click to write the first review

To post a review to our Facebook page, please click the Facebook Log In button above. Next type your Email or Phone and associated Username into the popup login panel and click the Log In button to sign into Facebook. Finally type your review in the box provided below and click the Post Review button.

Review:

The BMW M2/M3/M4 AST 5300 Series Coilovers product has been listed by Pumaspeed as fitting the following vehicles:

M2 (S58 - G87)

M3/M4 (S58-G80 G82)
